Titan Luber Series

Electro Luber Ball Bearing

Motor-driven automatic lubricators, the Titan CL Luber, Titan II and the Titan Oiler are reliable and easily refillable. They are suitable for industrial applications where quality and reliability are critical.

Microprocessor controlled allows energy-efficient motors to deliver lubricant to a fixed-displacement pump; can product pressures over 1,000 psi. This power and reliability allow the lubricators to pump grease through long feed lines and distribution blocks that can feed several applications simultaneously. This operation is not affected by temperature or altitude. Includes an internal blender which minimizes grease separation and enhances lube consistency.


  • Most powerful self-contained lubricator on the market
  • The Titan CL and Titan CL II produces over 1,000 psi which enables it to service single-point applications up to 30’ (9m) away and multi-point up to 20’ (6m) away with 1/4” ID tubing
  • Available with long-life replaceable battery packs or optional external power sources (AC or DC)
  • Refillable using a standard grease gun
  • Multiple settings to empty from 15 days to 2 years
  • Remote power and remove control options available
  • Suitable for indoor or outdoor use
  • Dustproof and weather resistant
  • Optional easy-to-install mounting plates for both single and multi-point applications available
  • Operating temperature range -4ºF to 131ºF (-20ºC to 55ºC)
  • LED operation and warming indicator (1-RED, 1-GREEN, 1-BLUE)
  • The Titan Oiler produces up to 2,000 psi which enables it to service single-point applications up to 200ft. away and multi-point applications up to 60ft. away
  • Titan Oiler has removable contaminant screen

Size & Dimensions

TITAN CL12″ high x 5″ wide x 7.5″ dia.
TITAN II12″ high x 5″ wide x 7.5″ dia.
TITAN OILER24 1/2″ high x 6″ wide x 8″ dia.
Titan I, Titan II and Titan Oiler Lubers

Titan Luber & Titan Oiler Installation
